• state: public - release: 02/06/2015

OIV

OIV	PDF	description	value
601	PDF	Mature leaf: length of vein N1	3	short (105 mm)
602	PDF	Mature leaf: length of vein N2	5	medium (105 mm)
603	PDF	Mature leaf: length of vein N3	5	medium (75 mm)
604	PDF	Mature leaf: length of vein N4	9	very long (55 mm and over)
605	PDF	Mature leaf: length petiole sinus to upper lateral leaf sinus	3	short (50 mm)
606	PDF	Mature leaf: length petiole sinus to lower lateral leaf sinus	3	short (45 mm)
607	PDF	Mature leaf: angle between N1 and N2 measured at the first ramification	7	large (56°-70°)
608	PDF	Mature leaf: angle between N2 and N3 measured at the first ramification	5	medium (46°-55°)
609	PDF	Mature leaf: angle between N3 and N41) measured at the first ramification	7	large (56°-70°)
610	PDF	Mature leaf: angle between N3 and the tangent between petiole point	9	very large (> 70°)
612	PDF	Mature leaf: length of tooth N2	3	short (10 mm)
613	PDF	Mature leaf: width of tooth N2	5	medium (14 mm)
614	PDF	Mature leaf: length of tooth N4	1	very short (6 mm)
615	PDF	Mature leaf: width of tooth N4	5	medium (14 mm)
617	PDF	Mature leaf: length between the tooth tip of N2 and the tooth tip of the first secondary vein of N2	3	short (30-45 mm)

superampelo

distances
descriptor	value	standard deviation
Length of vein N2	106.300	7.600
Width of petiole sinus / Distance between points SP and SP'	-3.900	4.100
Length of vein N3	79.500	7.700
Length of vein N2'	101.000	9.000
Distance between the tooth tip of N2 and the tooth tip of the first ramification (secondary vein) of N2	44.600	12.900
Length of vein N3'	75.500	8.700
Distance between the tooth tip of N2' and the tooth tip of the first ramification (secondary vein) of N2'	46.000	17.400
Distance from the petiole sinus to the lower right sinus	40.900	4.900
Distance from the petiole sinus to the lower left sinus	39.900	5.300
Distance from the petiole sinus to the upper right sinus	42.800	4.500
Distance from the petiole sinus to the upper left sinus	41.200	5.800
Vein N3, length from the petiole sinus to vein N4	11.900	1.600
Vein N3', length from the petiole sinus to vein N4'	12.800	2.100
Length of vein N5	26.200	1.700
Length of vein N5'	23.500	3.000
Length of vein N4	51.900	4.700
Length of vein N4'	48.200	6.800
Distance between petiole point and end of vein N4	60.300	6.300
Distance between petiole point and end of vein N4'	57.000	8.400
Leaf width	156.400	14.200
Leaf length	174.000	11.600
Petiole length	117.500	10.800
Leaf length Including the petiole	236.500	15.300
Distance between the ends of veins N2 and N2'	138.400	19.300
Length of vein N1	119.000	6.700
Distance between the ends of veins N4 and N4'	57.200	13.100
Distance between the ends of veins N3 and N3'	153.500	13.600

angles
descriptor	value	standard deviation
Angle between N1 and N2 measured at the first bifurcation	59.500	7.000
Angle between N2 and N3 measured at the first bifurcation	50.200	6.300
Angle between N1 and N2' measured at the first bifurcation	59.600	5.500
Angle between N3 and N4 at the first fork of N3	55.600	5.500
Angle between N2 and N3' measured at the first bifurcation	49.500	5.400
Angle between N1 and N2 measured at the ends of the veins	41.200	8.500
Angle between N3' and N4'	66.600	7.600
Angle between N2 and N3 measured at the ends of the veins	57.600	5.600
Angle between N1' and N2' measured at the ends of the veins	42.500	6.900
Angle between N3 and N4 measured at the ends of the veins	54.300	4.500
Angle between N2' and N3' measured at the ends of the veins	51.900	6.000
Angle of opening of the petiole sinus measured at SP and at SP'	11.100	6.200
Angle between N3' and N4' measured at the ends of the veins	54.600	4.900
Angle between S and S' with the center in N1	30.000	3.300
Angle between D and D' with the center in N1	102.600	9.600
Angle between N2 and N3 measured at the petiole point and between N2 and N3 tooth tip	79.600	7.800
Angle between I and I' with the center in N1	37.400	2.700
Angle between N2 and N3 measured at the petiole point and between N2' and N3' tooth tip	79.000	4.700

rations
descriptor	value	standard deviation
Multiplication between length and width of the leaf	27358.000	4124.000
Ratio between the length of the petiole OP and the length of the vein N1	0.989	0.080
Ratio between length and width of the leaf	1.115	0.041
Ratio between the distance from the sinus and the length of the vein N2	0.403	0.035
Media of the base of the teeth of the left side	7.582	1.628
Media of the base of the teeth of the right side	6.691	1.528
Media height of the teeth of the left side	6.126	1.454
Ratio between the height and the base of the tooth at the end of the vein N4'	0.594	0.116
Media height of the teeth of the right side	5.696	1.454
Ratio between the height and the base of the tooth at the end of the vein N2'	0.730	0.168
Ratio between the height and the base of the tooth at the end of the vein N4	0.602	0.160
Ratio between the height and the base of the teeth of the left side	0.841	0.287
Ratio between the height and the base of the tooth at the end of the vein N2	0.777	0.166
Ratio between the sum of the angles a' + b' and the sum of the distance between the petiole sinus and upper right sinus OS' and the petiole sinus and lower right lower right sinus OI'	0.024	0.002
Ratio between the height and the base of the teeth of the right side	0.886	0.256
Ratio between the length of the vein N5' and the length of the vein N1	0.198	0.024
Ratio between the sum of the angles a + b and the sum of the distance between the petiole sinus and upper right sinus OS and the petiole sinus and lower right lower right sinus OI	0.023	0.003
Ratio between the length of the vein N4' and the length of the vein N1	0.405	0.048
Ratio between the length of the vein N5 and the length of the vein N1	0.221	0.020
Ratio between the length of the vein N3' and the length of the vein N1	0.634	0.058
Ratio between the length of the vein N4 and the length of the vein N1	0.437	0.034
Ratio between the length of the vein N2' and the length of the vein N1	0.848	0.052
Ratio between the length of the vein N3 and the length of the vein N1	0.668	0.051
Ratio between the distance from the petiole sinus to the lower left sinus OI' and the length of vein N3'	0.529	0.037
Ratio between the length of the vein N2 and the length of the vein N1	0.894	0.045
Ratio between the distance from the sinus and the length of the vein N2'	0.408	0.049
Ratio between the distance from the petiole sinus to the lower right sinus OI and the length of vein N3	0.515	0.043
