• state: public - release: 26/05/2015

OIV

OIV	PDF	description	value
601	PDF	Mature leaf: length of vein N1	3	short (105 mm)
602	PDF	Mature leaf: length of vein N2	5	medium (105 mm)
603	PDF	Mature leaf: length of vein N3	5	medium (75 mm)
604	PDF	Mature leaf: length of vein N4	9	very long (55 mm and over)
605	PDF	Mature leaf: length petiole sinus to upper lateral leaf sinus	3	short (50 mm)
606	PDF	Mature leaf: length petiole sinus to lower lateral leaf sinus	3	short (45 mm)
607	PDF	Mature leaf: angle between N1 and N2 measured at the first ramification	3	small (30°-45°)
608	PDF	Mature leaf: angle between N2 and N3 measured at the first ramification	5	medium (46°-55°)
609	PDF	Mature leaf: angle between N3 and N41) measured at the first ramification	7	large (56°-70°)
610	PDF	Mature leaf: angle between N3 and the tangent between petiole point	7	large (56°-70°)
612	PDF	Mature leaf: length of tooth N2	3	short (10 mm)
613	PDF	Mature leaf: width of tooth N2	7	wide (18 mm)
614	PDF	Mature leaf: length of tooth N4	1	very short (6 mm)
615	PDF	Mature leaf: width of tooth N4	5	medium (14 mm)
617	PDF	Mature leaf: length between the tooth tip of N2 and the tooth tip of the first secondary vein of N2	3	short (30-45 mm)

superampelo

distances
descriptor	value	standard deviation
Distance from the petiole sinus to the lower right sinus	52.800	9.600
Distance from the petiole sinus to the lower left sinus	50.300	9.700
Distance from the petiole sinus to the upper right sinus	53.100	9.400
Distance from the petiole sinus to the upper left sinus	50.600	10.300
Vein N3, length from the petiole sinus to vein N4	13.300	1.900
Vein N3', length from the petiole sinus to vein N4'	13.300	3.000
Length of vein N5	20.000	5.500
Length of vein N5'	20.400	5.100
Length of vein N4	44.800	7.200
Length of vein N4'	44.100	5.700
Distance between petiole point and end of vein N4	56.000	7.900
Distance between petiole point and end of vein N4'	55.300	6.800
Leaf width	145.900	10.300
Leaf length	145.000	12.200
Petiole length	106.300	15.100
Leaf length Including the petiole	219.800	20.200
Distance between the ends of veins N2 and N2'	106.000	13.900
Length of vein N1	113.500	9.300
Distance between the ends of veins N4 and N4'	99.300	13.900
Distance between the ends of veins N3 and N3'	146.300	10.200
Length of vein N2	101.000	11.400
Width of petiole sinus / Distance between points SP and SP'	-34.500	4.900
Length of vein N3	76.600	8.800
Length of vein N2'	100.700	9.500
Distance between the tooth tip of N2 and the tooth tip of the first ramification (secondary vein) of N2	32.000	10.000
Length of vein N3'	75.400	7.900
Distance between the tooth tip of N2' and the tooth tip of the first ramification (secondary vein) of N2'	35.700	8.500

angles
descriptor	value	standard deviation
Angle between N1 and N2 measured at the first bifurcation	41.800	3.300
Angle between N2 and N3 measured at the first bifurcation	45.600	5.200
Angle between N1 and N2' measured at the first bifurcation	43.500	5.700
Angle between N3 and N4 at the first fork of N3	59.200	6.700
Angle between N2 and N3' measured at the first bifurcation	47.000	6.000
Angle between N1 and N2 measured at the ends of the veins	30.600	6.100
Angle between N3' and N4'	60.000	6.500
Angle between N2 and N3 measured at the ends of the veins	43.600	3.900
Angle between N1' and N2' measured at the ends of the veins	32.700	4.500
Angle between N3 and N4 measured at the ends of the veins	41.400	4.600
Angle between N2' and N3' measured at the ends of the veins	43.900	7.200
Angle of opening of the petiole sinus measured at SP and at SP'	102.900	20.800
Angle between N3' and N4' measured at the ends of the veins	41.100	3.400
Angle between S and S' with the center in N1	35.900	13.800
Angle between D and D' with the center in N1	93.000	7.400
Angle between N2 and N3 measured at the petiole point and between N2 and N3 tooth tip	62.200	8.300
Angle between I and I' with the center in N1	54.000	11.400
Angle between N2 and N3 measured at the petiole point and between N2' and N3' tooth tip	60.700	7.500

rations
descriptor	value	standard deviation
Media of the base of the teeth of the left side	5.800	0.961
Media of the base of the teeth of the right side	5.200	1.566
Media height of the teeth of the left side	4.299	0.734
Ratio between the height and the base of the tooth at the end of the vein N4'	0.518	0.109
Media height of the teeth of the right side	5.009	0.734
Ratio between the height and the base of the tooth at the end of the vein N2'	0.699	0.194
Ratio between the height and the base of the tooth at the end of the vein N4	0.425	0.050
Ratio between the height and the base of the teeth of the left side	0.765	0.204
Ratio between the height and the base of the tooth at the end of the vein N2	0.618	0.167
Ratio between the sum of the angles a' + b' and the sum of the distance between the petiole sinus and upper right sinus OS' and the petiole sinus and lower right lower right sinus OI'	0.016	0.003
Ratio between the height and the base of the teeth of the right side	1.045	0.368
Ratio between the length of the vein N5' and the length of the vein N1	0.180	0.040
Ratio between the sum of the angles a + b and the sum of the distance between the petiole sinus and upper right sinus OS and the petiole sinus and lower right lower right sinus OI	0.015	0.003
Ratio between the length of the vein N4' and the length of the vein N1	0.388	0.035
Ratio between the length of the vein N5 and the length of the vein N1	0.178	0.051
Ratio between the length of the vein N3' and the length of the vein N1	0.664	0.044
Ratio between the length of the vein N4 and the length of the vein N1	0.394	0.050
Ratio between the length of the vein N2' and the length of the vein N1	0.888	0.044
Ratio between the length of the vein N3 and the length of the vein N1	0.676	0.061
Ratio between the distance from the petiole sinus to the lower left sinus OI' and the length of vein N3'	0.673	0.140
Ratio between the length of the vein N2 and the length of the vein N1	0.889	0.065
Ratio between the distance from the sinus and the length of the vein N2'	0.506	0.112
Ratio between the distance from the petiole sinus to the lower right sinus OI and the length of vein N3	0.696	0.140
Multiplication between length and width of the leaf	21273.000	3269.000
Ratio between the length of the petiole OP and the length of the vein N1	0.939	0.129
Ratio between length and width of the leaf	0.993	0.024
Ratio between the distance from the sinus and the length of the vein N2	0.532	0.115
