• state: public - release: 20/06/2015

OIV

OIV	PDF	description	value
601	PDF	Mature leaf: length of vein N1	3	short (105 mm)
602	PDF	Mature leaf: length of vein N2	5	medium (105 mm)
603	PDF	Mature leaf: length of vein N3	5	medium (75 mm)
604	PDF	Mature leaf: length of vein N4	9	very long (55 mm and over)
605	PDF	Mature leaf: length petiole sinus to upper lateral leaf sinus	1	very short (30 mm)
606	PDF	Mature leaf: length petiole sinus to lower lateral leaf sinus	1	very short (30 mm)
607	PDF	Mature leaf: angle between N1 and N2 measured at the first ramification	7	large (56°-70°)
608	PDF	Mature leaf: angle between N2 and N3 measured at the first ramification	5	medium (46°-55°)
609	PDF	Mature leaf: angle between N3 and N41) measured at the first ramification	7	large (56°-70°)
610	PDF	Mature leaf: angle between N3 and the tangent between petiole point	9	very large (> 70°)
612	PDF	Mature leaf: length of tooth N2	3	short (10 mm)
613	PDF	Mature leaf: width of tooth N2	5	medium (14 mm)
614	PDF	Mature leaf: length of tooth N4	3	short (10 mm)
615	PDF	Mature leaf: width of tooth N4	5	medium (14 mm)
617	PDF	Mature leaf: length between the tooth tip of N2 and the tooth tip of the first secondary vein of N2	5	medium (46-55 mm)

superampelo

distances
descriptor	value	standard deviation
Distance from the petiole sinus to the lower right sinus	35.700	8.600
Distance from the petiole sinus to the lower left sinus	34.000	4.400
Distance from the petiole sinus to the upper right sinus	37.200	4.800
Distance from the petiole sinus to the upper left sinus	40.700	17.400
Vein N3, length from the petiole sinus to vein N4	8.900	1.900
Vein N3', length from the petiole sinus to vein N4'	10.700	2.400
Length of vein N5	26.000	4.400
Length of vein N5'	20.600	6.300
Length of vein N4	50.800	7.400
Length of vein N4'	47.900	6.300
Distance between petiole point and end of vein N4	57.300	7.300
Distance between petiole point and end of vein N4'	56.200	8.100
Leaf width	158.100	17.900
Leaf length	161.600	18.900
Petiole length	82.400	10.600
Leaf length Including the petiole	196.200	22.300
Distance between the ends of veins N2 and N2'	142.600	20.200
Length of vein N1	113.800	13.600
Distance between the ends of veins N4 and N4'	68.100	12.200
Distance between the ends of veins N3 and N3'	155.100	17.000
Length of vein N2	100.800	11.400
Width of petiole sinus / Distance between points SP and SP'	-10.200	1.900
Length of vein N3	76.500	8.300
Length of vein N2'	102.000	12.700
Distance between the tooth tip of N2 and the tooth tip of the first ramification (secondary vein) of N2	51.000	11.800
Length of vein N3'	79.500	10.200
Distance between the tooth tip of N2' and the tooth tip of the first ramification (secondary vein) of N2'	45.100	13.300

angles
descriptor	value	standard deviation
Angle between N1 and N2 measured at the first bifurcation	60.200	4.000
Angle between N2 and N3 measured at the first bifurcation	48.200	5.800
Angle between N1 and N2' measured at the first bifurcation	55.900	5.700
Angle between N3 and N4 at the first fork of N3	62.400	5.100
Angle between N2 and N3' measured at the first bifurcation	47.400	6.700
Angle between N1 and N2 measured at the ends of the veins	45.600	6.300
Angle between N3' and N4'	55.200	4.500
Angle between N2 and N3 measured at the ends of the veins	46.200	5.100
Angle between N1' and N2' measured at the ends of the veins	43.900	7.300
Angle between N3 and N4 measured at the ends of the veins	53.400	3.200
Angle between N2' and N3' measured at the ends of the veins	46.500	7.500
Angle of opening of the petiole sinus measured at SP and at SP'	26.200	11.700
Angle between N3' and N4' measured at the ends of the veins	50.600	5.500
Angle between S and S' with the center in N1	29.100	11.700
Angle between D and D' with the center in N1	101.100	10.700
Angle between N2 and N3 measured at the petiole point and between N2 and N3 tooth tip	85.800	8.200
Angle between I and I' with the center in N1	35.000	4.900
Angle between N2 and N3 measured at the petiole point and between N2' and N3' tooth tip	79.300	7.100

rations
descriptor	value	standard deviation
Media of the base of the teeth of the left side	7.086	1.571
Media of the base of the teeth of the right side	7.298	1.963
Media height of the teeth of the left side	5.840	1.093
Ratio between the height and the base of the tooth at the end of the vein N4'	0.612	0.134
Media height of the teeth of the right side	5.874	1.093
Ratio between the height and the base of the tooth at the end of the vein N2'	0.767	0.079
Ratio between the height and the base of the tooth at the end of the vein N4	0.712	0.095
Ratio between the height and the base of the teeth of the left side	0.851	0.234
Ratio between the height and the base of the tooth at the end of the vein N2	0.812	0.115
Ratio between the sum of the angles a' + b' and the sum of the distance between the petiole sinus and upper right sinus OS' and the petiole sinus and lower right lower right sinus OI'	0.026	0.007
Ratio between the height and the base of the teeth of the right side	0.852	0.329
Ratio between the length of the vein N5' and the length of the vein N1	0.178	0.036
Ratio between the sum of the angles a + b and the sum of the distance between the petiole sinus and upper right sinus OS and the petiole sinus and lower right lower right sinus OI	0.027	0.004
Ratio between the length of the vein N4' and the length of the vein N1	0.421	0.019
Ratio between the length of the vein N5 and the length of the vein N1	0.228	0.025
Ratio between the length of the vein N3' and the length of the vein N1	0.699	0.038
Ratio between the length of the vein N4 and the length of the vein N1	0.446	0.022
Ratio between the length of the vein N2' and the length of the vein N1	0.897	0.048
Ratio between the length of the vein N3 and the length of the vein N1	0.674	0.038
Ratio between the distance from the petiole sinus to the lower left sinus OI' and the length of vein N3'	0.430	0.043
Ratio between the length of the vein N2 and the length of the vein N1	0.887	0.033
Ratio between the distance from the sinus and the length of the vein N2'	0.401	0.173
Ratio between the distance from the petiole sinus to the lower right sinus OI and the length of vein N3	0.465	0.094
Multiplication between length and width of the leaf	25837.000	5995.000
Ratio between the length of the petiole OP and the length of the vein N1	0.726	0.064
Ratio between length and width of the leaf	1.022	0.021
Ratio between the distance from the sinus and the length of the vein N2	0.374	0.078
